Christie DHD550-G

Part Number: 140-001102-XX

The Christie® DHD550-G offers unsurpassed value and is a perfect fit for a variety of applications. Its single lamp design lowers total cost of ownership by reducing maintenance and energy cost. You get:
  • proven DLP® technology
  • excellent image quality
  • reliability
  • 5,500 center lumens – the brightest platform in its category
  • optional wireless connectivity
  • energy-saving features
  • low maintenance costs
  • many standard features
  • the best warranty and support in the industry
Technology 1-chip DLP
Resolution HD 1920 x 1080
Brightness 5,500 center lumens
Contrast Up to 5000:1
Illumination 370W P-VIP
Lamp life 1500 hrs minimum @ 370W 2000 hrs typical @ 280W
Length 15.28″ (388mm)
Width 17.13″ (435mm)
Height 8.15″ (207mm)
Weight 33.1 lb (15 kg)
Brightness
Brightness
  • 5,500 center (5,000 ANSI) lumens
Contrast
  • 5000:1
Display technology and resolution
  • 1-chip 0.65″ DMD
  • 1920 x 1080 HD
Lamp
  • 370W P-VIP
Input signal compatibility
  • HDTV formats VGA through to WUXGA (1920 x 1200)
  • Horizontal and vertical scaling while maintaining aspect ratio, all inputs
Pixel clock
  • 162 MHz
Scan rates
  • Horizontal: 15 kHz to 100 kHz
  • Vertical: 24 kHz to 85 kHz
Inputs, control and networking
  • HDMI x 1
  • DVI-D x 1 (digital only)
  • DisplayPort x 1
  • HD15 x 1
  • Composite video x 1 (RCA)
  • S-Video x 1 (mini DIN)
  • Component video (RCA)
  • USB x 1 (type B mini) – display over USB
  • USB x 1 (type A) – image viewer or WiFi dongle (optional)
  • RJ45 x 1
  • RS232 in
  • Ethernet (10/100) RJ45 with ChristieNET connectivity
  • Build-in backlit keypad
  • Wired remote control (3.5mm stereo) – wire not included
Optical system
  • Motorized zoom, focus and lens shift and mechanical light shutter
Lenses
  • 0.95-1.22:1 (HD) zoom lens
  • 1.22-1.52:1 (HD) zoom lens
  • 1.52-2.89:1 (HD) zoom lens
Offsets
  • Vertical: +/-120% (+/- 648 pixels)
  • Horizontal: +/-20% (+/-192pixels)
Standard accessories
  • IR remote w/ wired remote jack (wire not included)
  • AC line cord for projector head
  • User manual
Optional accessories
  • Wireless dongle
  • Warp module
  • Cable cover
  • Ceiling mount
  • Ceiling mount extension rod
Power requirements
  • Operating voltage: 100 VAC to 240 VAC @ 50/60 Hz
  • Operating current: 6A max
  • Power consumption: 510W max, 405W eco mode
  • Dissipation: 1740 BTU/hr max, 1382 BTU/hr eco mode
Dimensions and weight
  • Size: (L x W x H): 15.28 x 17.13 x 8.15” (388 x 435 x 207 mm) excluding feet
  • Shipping size: 19.49 x 23.03 x 16.14″ (495 x 585 x 410mm)
  • Weight: 33.1 lb (15 kg)
  • Shipping Weight: 41.2 lb (18.7 kg)
Operating environment
  • Temperature: 40 – 95°F (5 – 35°C)
  • Humidity: 0 – 90% non-condensing
Regulatory approvals
  • UL/CSA/IEC 60950-1
  • FCC Class A, CE, CCC, KC, Gost-R, PSE, C-tick, and South Africa.
  • This product conforms to all relevant European directives, standards, safety, health and environmental concerns
  • RoHS, REACH, WEEE
Limited warranty
  • 3 years parts and labor (including light engine)
  • Contact an authorized Christie representative for full details of our limited warranty


Features

  • single-lamp design
  • 1-chip DLP technology for excellent image quality and reliability
  • filter-free and dust-sealed for low maintenance and costs
  • Dynamic Contrast, which enhances images by increasing the contrast ratio to 5000:1
  • an optional wireless module for device flexibility and easy presentation set-up
  • built-in color matching for a more uniform image in a multiple projector configuration
  • blending and warping capabilities for curved surfaces
  • 24/7 use capability
  • eco-friendly features
