Christie D4K3560

Part Number: 129-005106-XX

The Christie D4K3560 projector with 35,000 center lumens, has native 4K (4096 x 2160) resolution. It offers ultra-realistic images, higher brightness and smoother video at 60Hz, thanks to new and unique Christie TruLife™ electronics – a quantum leap in video-image processing that boasts a breakthrough in high frame rate and high-resolution video projection.

This projector’s superior 3-chip DLP® performance and durability make it ideal for large applications such as amusement parks, auditoriums, casinos, classrooms, museums, planetariums, theaters and virtual design centers.

Technology 3-chip DLP
Resolution 4096 x 2160 4K
Brightness 35,000 center lumens – 6.0kW lamp
29,000 center lumens – 4.5kW lamp
19,500 center lumens – 3.0kW lamp
13,000 center lumens – 2.0kW lamp
Contrast Up to 2000:1
Lamp life 6.0 kW – 750 hours
4.5 kW – 900 hours
3.0 kW – 2,500 hours
2.0 kW – 3,500 hours
Length 51.1″ (1298 mm)
Width 25.5″ (648 mm)
Height 19.0″ (483 mm)
Weight 251 lbs (114 kg) (without lens)
  • 35,000 center lumens
  • 2000:1 contrast ratio
Brightness
  • 35,000 center [32,500 ANSI] lumens – 6.0 kW lamp
  • 29,000 center [27,000 ANSI] lumens – 4.5 kW lamp
  • 19,500 center [18,000 ANSI] lumens – 3.0 kW lamp
  • 13,000 center [12,000 ANSI] lumens – 2.0 kW lamp
Display
  • 3-chip 1.38” DMD
  • Native 4K (4096 x 2160)
Lamp
  • Xenon bubble, user-replaceable bulb1
  • 6.0kW lamp CDXL-60 – 750 hours
  • 4.5kW lamp CDXL-30 – 900 hours
  • 3.0kW lamp CDXL-20 – 2,500 hours
  • 2.0kW lamp CDXL-20 – 3,500 hours
Signals

Standard

  • 2x Dual 3G HD-SDI input card
  • 2x Twin display port input card

Optional

  • Dual link DVI input card
  • Twin HDMI input card

Signal inputs

  • Accepts 4K (4096×2160) and Quad HD (3840×2160)

  • 4 x DisplayPort 1.1a
    • 4K/Quad HD – 24 to 60Hz 4:4:4 8-/10-bit
    • 4K/Quad HD – 24 to 60Hz 4:2:2 8-/10-/12-bit
  • 2 x DisplayPort 1.1a
    • 4K/Quad HD – 24 to 60Hz 4:4:4 8-/10-bit
  • 4 x HD SDI
    • 4K/Quad HD – 24 to 30Hz 4:4:4 12-bit (4 x 3G HD-SDI)
    • 4K/Quad HD – 24 to 30Hz 4:2:2 12-bit (4 x 3G HD-SDI)
    • 4K/Quad HD – 24 to 30Hz 4:2:2 10-bit (4 x HD-SDI)
    • 4K/Quad HD – 50 to 60Hz 4:2:2 10-bit (4 x 3G HD-SDI)
  • 4 x DVI
    • 4K/Quad HD – 24 to 60Hz RGB 8-bit
  • 2 x DVI (Dual Link)
    • 4K/Quad HD – 24 to 60Hz RGB 8-bit

Signal outputs – loop-out

  • Dual 3G HD-SDI input card, twin DisplayPort input card

Inputs, control and networking
  • RS-232
  • Ethernet (10/100) RJ45 with ChristieNETTM connectivity
  • Detachable LCD control module
Lens mount

Type

  • Tool-free lens insertion system
  • Boresight adjustable

Motorized

  • Horizontal and vertical offset
  • Focus
  • Zoom
Lenses

Fixed

  • 0.72:1 (no offset)
  • 1.0:1 (Offset: Vertical: ± 29%  Horizontal: 9%)

Zoom

  • 1.13-1.31:1 (Offset: Vertical: ± 56%  Horizontal: 19%)
  • 1.31-1.63:1 (Offset:  Vertical: ± 13%  Horizontal: 4%)
  • 1.63-2.17:1 (Offset: Vertical: ± 13%  Horizontal: 4%)
  • 1.98-2.71:1 (Offset: Vertical: ± 13%  Horizontal: 4%)
  • 2.71-3.89:1 (Offset: Vertical: ± 13%  Horizontal: 4%)
  • 3.89-5.43:1 (Offset: Vertical: ± 13%  Horizontal: 4%)
  • 5.43:1-7.69:1 (Offset: Vertical: ± 56% Horizontal: 19%)
Accessories

Standard

  • Detachable LCD control module
  • AC line cord for projector head
  • Detached 7kW low-ripple switch mode lamp ballast (required to operate projector)
  • CDXL-60 lamp

Optional

  • CDXL-20 lamp
  • CDXL-30 lamp
  • CDXL-45 lamp
  • Heat extraction fan kit (required when operating the projector)
  • Rack mount pedestal
  • Replacement air filter for the light engine
  • Replacement air filter for the liquid cooling radiator
  • Lamp adapter kit for CDXL-20
  • Christie Twist 4K (limited to 30 frames per second)
Power requirements

Projector head

  • Operating voltage: Single phase 200-240 VAC @50/60Hz
  • Operating current: 7A max at 200V

Ballast

  • Type: detached, 7kW low-ripple, switch-mode lamp ballast
  • Operating voltage: 3-phase 200-230 VAC @ 50/60Hz
  • Operating current: 38A per phase max
  • Operating voltage: 3-phase 380-415 VAC @ 50/60Hz
  • Operating current: 26A per phase max
Dimensions

Size

  • Projector head (LxWxH): 51.1 x 25.5 x 19.0″ (1298 x 648 x 483mm)
  • Ballast (LxWxH): 21 x 18 x 21″ (533 x 457 x 533mm)

Shipping size

  • Projector head (LxWxH): 60.4 x 36.0 x 28.5″ (1535 x 914 x 724mm)
  • Ballast (LxWxH): 28.0 x 25.0 x 31.5″ (710 x 635 x 800mm)

Weight

  • Projector head 251lbs (114kg)
  • Ballast 89lbs (40.5kg)

Shipping weight

  • Projector head 322lbs (146kg)
  • Ballast 135lbs (62kg)
Operating environment
  • Operating temperature: 50-95°F (10-35°C)
  • Humidity (noncondensing): 20-80%
Regulatory approvals

This product conforms to these regulations related to product safety, environmental requirements and electromagnetic compatibility (EMC):

Directives:

  • (EC) 2011/65/EU (RoHS)
  • 2012/19/EU (WEEE)

Regulations:

  • (EC) No. 1907/2006 (REACH)
  • CAN/CSA C22.2 No. 60950-1
  • UL 60950-1
  • IEC 60950-1
  • EN 60950-1
  • FCC, Part 15, Subpart B, Class A
  • EN55022/CISPR22 Class A
  • EN55024/CISPR24

The product is designed to comply to the rules and regulations required for the product to be sold in various regional markets, including: USA/Canada, EU, Norway, Australia/New Zealand, Kuwait, China, Korea, Japan, Mexico, Ukraine, Russia, South Africa, and Saudi Arabia.

Limited warranty
  • Three years parts and labor (including light engine)
  • Contact an authorized Christie representative for the full details of our limited warranty.

Due to constant research, specifications and features are subject to change without notice.

1 – User-replaceable bulb
2 – Some features may not be functional on initial product shipments but will be enabled via software upgrade when available.



With the Christie D4K2560 you get:

  • Four times the resolution of 2K
  • 3-chip DLP technology for longer life and richer color
  • High frame rate 60Hz
  • High brightness
  • Flexible input options
  • Cleanable optical engine

Depending on your application needs, there are different Christie D4K3560 lamp powers to choose from. And, the motorized lens mount, user-replaceable lamps and field-alignable DMDs ensure that set up is fast, and maintenance time and costs are reduced.

Capture your audience’s attention with precise detail and vibrant life-life images, with a projector designed to help you put on a breathtaking show.

Choose the Christie D4K3560, backed by Christie’s industry-leading warranties,service and support.
