Mirage HD10K-M

Part Number: 118-051107-XX

The Christie Mirage HD10K-M delivers visually stunning 3D for home theatre and entertainment, museums and education, scientific research, manufacturing, oil and gas exploration and anything in between. Offering complete compatibility with today’s 3D home entertainment requirements, the Christie Mirage HD10K-M is ready for Blu-ray 3D video, PS3 and other gaming consoles and meets the mandatory 3D spec for HDMI v1.4a.
Technology 3-chip DLP®
Resolution HD (1920 x 1080)
Brightness 10,000 ANSI Lumens
Contrast 650:1 ANSI / 2,500-10,000:1 FOFO
Illumination Dual Osram® PvIP® 350W lamps
Lamp life (typical) 1500 hrs @350W, 2000 hrs @300W
Height 10.2″ (259 mm)
Width 19.7″ (500 mm)
Depth 22.1″ (561 mm)
Weight 55 lbs (25 kg)
  • 10,000 ANSI lumens
  • 2,500-10,000:1 FOFO
  • 650:1 ANSI
  • Electronically adjustable iris (manual or dynamic)
Display Technology and Resolution
  • 3-chip 0.95” DMD
  • Full HD 1920 x 1080
  • As little as one frame
Input signal compatibility
  • Native dual-link DVI-D
  • Analog BNC (optional)
  • Frame-doubled 3D – dual-link DVI, VGA
  • (HDMI, analog BNC and SDI optional)
  • Pixel clock: 330MHz
Scan rates
  • H – 15 kHz to 120 kHz
  • V – 23.97 Hz to 150 Hz (up to 120Hz maximum output)*
Inputs, control & networking
  • RS232 in/out
  • RS422 in
  • Ethernet (10/100)
  • USB device
  • GPIO (RS232 9-pin male connector)
  • Built-in backlit LCD keypad
  • Remote control (with optional wired XLR connection)
  • Slot 1-2 standard (populated): Dual link DVI-D (330MHz) and VGA (165MHz)
Optional input modules
  • Slots 3-4 unpopulated
  • Full bandwidth analog BNC
  • Dual-link DVI input card (330MHz), VGA (165MHz)
  • Dual SD/HD-SDI
  • Video decoder
  • Twin HDMI
Lens mount and illumination
  • Motorized horizontal and vertical lens offset
  • Scheimpflug (tilt) adjustment
  • Built-in light shutter
  • Tool-free lens insertion system
  • All lenses are optional
  • Dual Osram PvIP 200W lamps
  • Lamp life: 1500 hrs @350W, 2000 hrs @300W
Lenses (fixed)
  • Christie ILS lens 0.73:1 SX+ / 0.67:1 HD*
  • Christie ILS lens 1.2:1 SX+ / 1.1:1 HD

*Maximum refresh rate is 120Hz

Lenses (zoom)
  • Christie ILS lens 1.25-1.6:1 SX+ / 1.16-1.49:1 HD**
  • Christie ILS lens 1.5-2.0:1 SX+ / 1.4-1.8:1 HD
  • Christie ILS lens 2.0-2.8:1 SX+ / 1.8-2.6:1 HD
  • Christie ILS lens 2.8-4.5:1 SX+ / 2.6-4.1:1 HD
  • Christie ILS lens 4.5-7.5:1 SX+ / 4.1-6.9:1 HD
  • Christie ILS lens 7.5-11.2:1 SX+ / 6.9-10.4:1 HD

*Maximum refresh rate is 120Hz

Offsets
  • +/- 120% Vertical
  • +/- 54% Horizontal
  • (* +/- 23%V +/- 13%H)
  • (** +/-70%V +/- 45%H)
Power requirements
  • Operating voltage: 100 VAC to 240 VAC @ 50/60 Hz
  • Operating current: 12A @ 100 V
  • Power: 1320 W
  • Dissipation: 4508 BTU/hr
Enhanced feature sets
  • Embedded Christie Twist™ – internal advanced warping and edge-blending
  • LiteLOC™
  • Electronically adjusted iris (manual or dynamic)
  • Dust-sealed, filter-free design
  • Reduced power requirements (as compared to competitive products on the market today) – at maximum brightness the unit only draws 870W; standby power consumption (phantom power draw) is less than 20W.
  • Reduced noise levels
  • LCD keypad – active keys are amber to indicate whether function selected will be seen by the audience
  • Motorized yellow notch filter
  • Built-in portrait display capabilities*

*Christie M Series stacking frame is required in portrait orientation.

Standard accessories
  • User manual
  • IR remote
  • Line cord
  • Two dual-link DVI-D cards
  • 3D sync cable
Optional accessories
  • Coarse dust filter
  • ILS lens adapter kit
  • Stacking frame dual HD/SDI input card
  • Twin HDMI input card
  • Video decoder input card*

*may not include 3D support

Dimensions
  • Size: (L x W x H): 22.1 x 19.7 x 10.2″ (561 x 500 x 259mm)
  • Weight: 55 lb (25 kg) (without lens)
  • Shipping weight: 87 lb (38 kg) (without lens)
Operating Environment
  • Operating temperature: 40-104°F (5-40°C)
  • Humidity (non-condensing): 20-80% non-condensing
Regulatory Approvals
  • UL/CSA/IEC 60950 (3rd edition)
  • FCC Class A, CE, CCC
  • This product conforms to all relevant European directives, standards, safety, health and environmental concerns
  • RoHS, WEEE
Warranty
  • 3 years parts and labor (including light engine)
  With dual image processing capabilities, there are three modes of 3D input – native 3D input, frame doubled 3D and Dual Input 3D for maximum source compatibility and high-performance flicker-free operation without the need of a passive to active converter.

Features

  • HD resolution (1920 x 1080)
  • 10,000 ANSI lumens
  • Up to a full 120Hz native frame rate
  • Dual image processing with two standard full 330MHz dual-link DVI-D input cards
  • Variable contrast ratio using electronically adjustable iris for crisp, detailed images – 2500-10,000:1 (full on, full off) / 650:1 ANSI
  • At maximum brightness the projector draws a maximum power of 1320W
  • Smallest chassis in its class
  • Motorized yellow notch filter
  • Dual Osram PviP lamps (200W)
  • Embedded Christie Twist™ image warping and edge-blending
  • Dust-sealed engine, filter-free design
  • Intelligent Lens System (ILS™) for zoom, focus, horizontal and vertical offset
  • AutoDesk® Revit® model
  • Built-in portrait display capabilities*

**Christie M Series stacking frame is required in portrait orientation.

The Christie Mirage HD10K-M features 6000 ANSI lumens, HD resolution and up to 10,000:1 contrast. Combined with embedded Christie Twist™, additional standard features, an expanded lens suite and industry-leading Christie warranties, service and support, the Christie Mirage M Series provides high-performance and ease of use for high-performance 3D users. When you want high-performance 3D displays, think Christie Mirage M Series. The most compact 3-chip DLP® active stereo projector in its class, the series of 6 models deliver crisp, detailed images with excellent color and brightness.
