Christie LHD700

Part Number: 103-034108-XX

This single-lamp, portable projector features 7000 ANSI lumen brightness, full HD resolution, 4DColor™ technology and inorganic LCD panels for high contrast and vivid color presentations. 4DColor™ technology gives a 20 percent increase in color gamut over comparable 3LCD models.
Technology 3LCD
Resolution HD (1920 x 1080)
Brightness 7000 ANSI Lumens
Contrast 3000:1 (Full on/off)
Illumination 380W NSHA
Lamp Life 2,000 hours, up to 3,000 in eco mode
Height 7.36″ (439.9 mm)
Width 14.5″ (370.0 mm)
Depth 17″ (187.0 mm)
Weight 25.1 lb (11.4 kg)
  • 7000 ANSI lumens
  • Contrast Ratio: 3000:1 (full on/off)
  • 90% Brightness Uniformity (corner to corner)
Display technology
  • 3 x 1.2″ Inorganic LCD
  • Full HD 1920 x 1080
Lamp
  • 380W Ushio NSHA x1
  • Normal Mode: 2000 hours
  • Eco Mode: 3000 hours
Input Signal Compatibility
  • UXGA/SXGA+/SXGA/WXGA/XGA/SVGA/VGA, MAC, NTCS, PAL, SECAM, NTSC4.43, PAL-M, PAL-N . Video (480i, 480P, 720P, 1080i, 1080p, 1080psf )
Pixel Clock
  • 162 MHz. Analog ; 162 MHz Digital
Scan Rates
  • Horizontal: 15kHz to 120kHz
  • Vertical: 38Hz to 120Hz
Inputs, Control and Networking
  • Input #1: DVI-D x 1 (HDCP Compatible ), HDMI (V1.3 with DeepColor Compatible)
  • Input #2: BNC x 5 (R, G, B, H, V & Y, Pb/Cb, Pr/Cr & Composite), D-sub 15 x 1
  • Input #3: S-Video -DIN 4-pin x 1 ; RCA x3 (Video/Y, Pb/Cb,Pr/Cr)
  • Control: Serial Input – Dsub-9×1; CCM-LX input connector
  • Network: RJ-45 x1 (LAN)
  • Serial Output: Dsub-9 x 1. R/C jack: mini jack x 1
Optical System
  • Motorized zoom, focus and lens shift
  • Mechanical light shutter
Lenses
    • Fixed
    • Short 0.8:1
    • Zoom
    • Short 1.3-1.8:1
    • Standard 1.8-2.3:1
    • Semi long 2.3-4.2:1
    • Long Zoom 4.3-6.0:1
    • Ultra Long 5.7-9.0:1
    • Digital Keystone
    • V +/- 40°, H +/- 20° and 3D Keystone™
Accessories
    • Standard
    • Quick setup manual
    • Real Color Management software instruction
    • Lens spacer for option lenses
    • Light-block sheet
    • Mounting clamp
    • Lens cover strap
    • Power cord
    • AC cord UL type (NEMA 6-20P plug type) 3 meters
    • AC cord European2P plug type 3 meters
    • Computer cable (Dsub15-Dsub15)
    • Remote control
    • Optional
    • CCM-LX Network Module
    • 380W USHIO NSHA lamp
    • AutoFilter cartridge
Enhanced feature sets
  • 4DColor™ technology
  • Crestron RoomView™
  • AMX Device Discovery
  • Edge blending and color matching
  • 360 degree on-axis rotation
  • PiP and PbyP
  • *Stackable design for redundancy or added brightness
  • Digital keystone
  • AutoFilter cartridge (up to 10,000 hours) maintenance free operation
  • Customizable start-up logo
  • Native 16:9; selectable aspect ratio 4:3 and true mode
  • Intuitive graphical user interface
  • Built-in keypad (power on/standby, menu, up, down, left, right arrows)
  • Front and rear infrared sensors for IR keypad
  • Auto discoloration prevention with 3D-AUCC technology
  • Top access to LCD panels- simplifies cleaning and maintenance
*In a stacked setup, this projector is best suited for events or temporary use. The projector may need to be re-aligned if it is used in a fixed-installation application
Power requirements
  • Operating voltage: 100-120 V AC +/- 10% / 200-240 V AC +/- 10%
  • Operating current: 6.0 A
  • Power: 520 W (Lamp Normal 100-120V), 500 W (Lamp Normal 200-240V)
  • Dissipation: 2020 BTU/h
Dimensions (LxWxH)
  • Body size (LxWxH): 17 x 14.5 x 7.36″ (439.9 x 370.0 x 187.0mm) – body only, without  lens; feet at minimum height position
  • Shipping size (LxWxH): 24.8 x 19.3 x 15.2″ (630x 492x 388mm)
  • Weight: 25.1lb (11.4kg) (without lens)
  • Shipping Weight: 35.1lb (15.9kg) without Lens
Noise
  • 42dBA standard mode
  • 38dBA eco mode
Operating environment
  • Temperature: 41°F to 104°F (5°C to 40°C)
  • Storage temperature: 14˚F to 140˚F (-10˚C to 60˚C)
  • Humidity: 20% to 80% non-condensing
Regulatory Approvals
  • Directives (EC) 2002/95/EC (RoHS); 2002/96/EC (WEEE)
  • Regulation (EC) No. 1907/2006 (REACH); CAN/CSA C22.2 No. 60950-1; UL 60950-1; IEC 60950-1; FCC, Part 15, Subpart B, Class A; EN55022/CISPR22 Class A; EN55024 / CISPR24
    • Certifications marks:
    • cULus (Canada and US)
    • CE (EU)
    • CCC (China)
    • GoST-R (Russia)
Limited Warranty
  • Projector: three years parts and labor
  • Lamp: 500 hours or one year (whichever comes first)
  • Contact an authorized Christie representative for full details of our limited warranty
  The Christie LHD700 is easy to set up and use with motorized lenses and 3D Keystone™ capabilities. A variety of input connections and a suite of optional lenses ensure that the Christie LHD700 can meet your application requirements. Crestron’s RoomView® and AMX Discovery Device make it easy and quick to configure third-party equipment with this projector. The AutoFilter, easy lamp access and up to 3000 hours lamp life (eco mode) help reduce projector downtime, and service and maintenance costs. The Christie LHD700 brings full HD resolution in a single-lamp, portable design that’s affordable and maintains high performance for medium-sized applications.

Features

  • 4DColor technology for life-like color performance
  • Inorganic LCD panels create a natural black state for increased contrast ratio and sharper images
  • Motorized lens shift, zoom and focus
  • Easy set-up with H/V digital keystone correction and 3D Keystone geometry correction, color matching and edge blending
  • Crestron’s RoomView® and AMX Discovery Device option
  • Built-in network capabilities by Ethernet
  • Up to 10,000 hour AutoFilter cartridge
  • * Stackable for redundancy or added brightness up to 14,000 ANSI lumens
* In a stacked setup, this projector is best suited for events or temporary use. The projector may need to be re-aligned if it is used in a fixed-installation application Christie LHD700 can also be used with the Christie YK50 as a moving digital luminaire system. The Christie YK50 is a small, dual-arm yoke that supports either the Christie LX700 or Christie LHD700 projector, offering a 7000 ANSI lumens LCD option for moving video projection. The combination of the Christie YK50 with either of these projectors gives you bright, real-color, moving digital images, lighting and video displays – ideal for small- to mid-size venues.
