Christie DHD600-G

Part Number: 140-003104-XX

The Christie® DHD600-G offers unsurpassed value and is a perfect fit for a variety of applications. Its single lamp design lowers total cost of ownership by reducing maintenance and energy cost. You get:
  • single-lamp design
  • 1-chip DLP technology for excellent image quality and reliability
  • built-in color matching for a more uniform image in a multiple projector configuration
  • blending and warping capabilities for curved surfaces
  • 24/7 use capability
  • 2,000 hours long lamp life contributes to a low cost of ownership
  • filter-free and dust-sealed for low maintenance and costs
  • eco-friendly features
  • Dynamic Contrast, which enhances images by increasing the contrast ratio to 4800:1
  • an optional wireless module for device flexibility and easy presentation set up
  • DICOM simulation
Technology 1-chip DLP
Resolution HD 1920 x 1080
Brightness 6,200 center lumens
Contrast Up to 5000:1
Illumination 465W NSH
Lamp life 2000 hrs minimum @ 465W2500 hrs typical @ 360W
Length 15.28″ (388mm)
Width 17.13″ (435mm)
Height 8.15″ (207mm)
Weight 33.7 lb (15.3 kg)
Brightness
  • 6,200 center (5,950 ANSI) lumens
Contrast
  • 4800:1 (dynamic contrast enabled)
  • 1200:1 (full on/ full off)
  • 250:1 (ANSI)
Display technology and resolution
  • 1-chip 0.65″ DMD
  • 1920 x 1080 HD
Lamp
  • 465W NSH
  • 2000 hrs minimum @ 465W
  • 2500 hrs typical @ 360W
Input signal compatibility
    • Standard
    • 1x HDMI
    • 1x DVI-D (digital only)
    • 1x DisplayPort
    • 1x HD15
    • 1x RCA (composite video)
    • 1x S-Video (mini DIN)
    • Component video (RCA)
    • 1x USB (type B mini) – display over USB
    • 1x USB (type A) – image viewer or Wi-fi dongle (optional)
    • 1x RJ45
    • Signals
    • HDTV formats VGA through to WUXGA (1920 x 1200)
    • Horizontal and vertical scaling while maintaining aspect ratio, all inputs
Pixel clock
  • 162 MHz
Scan rates
  • Horizontal: 15 kHz to 100 kHz
  • Vertical: 24 kHz to 85 kHz
Outputs
  • ​1x HD15
Control and networking
  • RS232 in
  • Ethernet (10/100) RJ45 with ChristieNET connectivity
  • Build-in backlit keypad
  • Wired remote control (3.5mm stereo) – wire not included
Optical system
  • Tool-free lens insertion system
  • Boresight adjustable
  • Motorized zoom, focus and lens shift
Lenses
  • 1.22-1.52:1 (HD) zoom lens (included)
  • 1.52-2.89:1 (HD) zoom lens (optional)
  • 0.95-1.22:1 (HD) zoom lens (optional)
Offsets
  • Vertical: +/- 120% (+/- 648 pixels)
  • Horizontal: +/-20% (+/-192pixels)
Standard accessories
  • IR remote w/ wired remote jack (wire not included)
  • AC line cord for projector head
  • User manual
Optional accessories
  • 1DWUSB-BGN (Wireless dongle)
  • Warp module
  • Cable cover
  • Ceiling mount
  • Ceiling mount extension
Power requirements
  • Operating voltage: 100 VAC to 240 VAC @ 50/60 Hz
  • Operating current: 6.5A max
  • Power consumption: 580W max, 450W eco mode
  • Dissipation: 1979 BTU/hr max, 1535 BTU/hr eco mode
Dimensions and weight
  • Size: (L x W x H): 15.28 x 17.13 x 8.15” (388 x 435 x 207 mm) without feet
  • Shipping size: 23.27 x 23.03 x 17.44″ (591 x 501 x 443mm)
  • Weight: 33.7 lb (15.3 kg)
  • Shipping Weight: 45.2 lb (20.5 kg)
Operating environment
  • Temperature: 40 – 95°F (5 – 35°C)
  • Humidity: 10 – 85% non-condensing
Regulatory approvals
  • UL/CSA/IEC 60950-1
  • FCC Class A, CE, CCC, KC, EAC, PSE, CU, SABS, BIS and RCM
  • This product conforms to all relevant European directives, standards, safety, health and environmental concerns
  • This product is designed to comply to the rules and regulations required for the product to be sold in various regional markets, including USA/Canada, EU, Norway, Australia/New Zealand, Kuwait, China, Korea, Japan, Mexico, Ukraine, India, Russia, South Africa and Saudi Arabia
  • RoHS, REACH, WEEE
Limited warranty
  • 3 years parts and labor (including light engine)
  • Contact an authorized Christie representative for full details of our limited warranty
